Specifications
General Information
| Manufacturer | Kingston Technology Company |
| Manufacturer Part Number | SEDC1000M/7680G |
| Manufacturer Website Address | http://www.kingston.com |
| Brand Name | Kingston |
| Product Series | DC1000M |
| Product Name | Enterprise Class U.2 NVMe SSD with PLP |
| Product Type | Solid State Drive |
Technical Information
| Storage Capacity | 7.50 TB |
Drive Performance
| Maximum Read Transfer Rate | 3100 MB/s |
| Maximum Write Transfer Rate | 2800 MB/s |
| Random 4KB Read | 485000IOPS |
| Random 4KB Write | 210000IOPS |
| Endurance (DWPD) | 1 |
| Endurance (TBW) | 13450 TB |
| Endurance Type | Mixed Use |
Network & Communication
| Wireless LAN | No |
Interfaces/Ports
| Drive Interface | U.2 (SFF-8639) NVMe |
| Drive Interface Standard | PCI Express NVMe 3.0 x4 |
Physical Characteristics
| Drive Type | Internal |
| Form Factor | 2.5" |
| Hot Pluggable | Yes |
| Height | 0.6" |
| Width | 2.7" |
| Depth | 3.9" |
| Weight (Approximate) | 5.64 oz |
Miscellaneous
| Device Supported | Storage System |
| Server | |
| Country of Origin | Taiwan |
| Environmentally Friendly | Yes |
| Environmental Compliance | Waste Electrical and Electronic Equipment Directive (WEEE) |
| Restriction of Hazardous Substances (RoHS) | |
| China Restriction of Hazardous Substances (China RoHS) |
Warranty
| Limited Warranty | 5 Year |
